000M Ethernet Surge Protective Device
HF-SPD-E1000 Ethernet Surge Protective Device is specially designed for the front-end protection of lightning network equipment. It is installed on the front end of the network equipment, using high-energy anti-surge components, the back-end equipment can be protected from the damages of induced over-voltage, switching over-voltage and ESD etc. HF-SPD-E1000 is with differential and common-mode surge protection on signal lines to meet the electrical characteristics of Gigabit Ethernet signal lines. Using design of industrial wide temperature range, with performance of dustproof, salt-spray proof, anti-acid fog, and suitable for harsh working environment.
High current capacity, fast response
Differential and command mode protection, fast response, low residual voltage
Small leakage current and rate of change
Internationally renowned core components with excellent, stable and reliable performance
Grounding point via a special process and avoid signal interference
Standard modular design,easy installation and maintenance
RJ45 connector comply with command standart of PoE network equipment communication
Long time working under harsh environment, such as acid, alkaline, dusty, salty spray and humid environment acid, alkaline, dusty, salty spray and humid environment
Electrial properties | |
Object of protection | Network devices with Ethernet interfaces, Such as Ethernet switches, POE cameras etc. |
Operating votalge | AC/DC48V |
Protection | Industrial level 4, command-mode 4000V, difference mode 2000V |
Maximum dischage current(Imax) | 10KA |
Insertion loss | 0.1dB |
Response time | ＜1ns |
Maximum transfer rate | 1000Mbps |
Protection pin | 1/2/3/4/5/6/7/8 |
Interface | RJ45 |
Environmental Limit | |
Storage Temperature | -40 to 85ºC |
Operating Temperature | -40 to 85ºC |
Operating Humidity | 5% to 95% Non-condensing |
MTBF | Š100000 hours |
Protection level | IP40, optional higher level |
Physical Characteristic | |
Installation | Wall mounting |
Dimension (W x D x H) | 183×95×25.4mm(8 channel) 86×26×26mm(1 channel) |
Weight(kg) | 0.55kg |
HF-SPD-E1000-8
HF-SPD-E1000-1
